EASyS Advantage
Maximum driving comfort for an easy-going day
Features and Benefits:
Sitting for long periods can be tiring, but sometimes it can not be avoided. So it is good if the pediatric wheelchair is perfectly adaptable – due to its many setting options – and luxuriously soft. The child can then sit or lie in the cozy, comfortable cushions for a long time.
Technical Data
1. back height 2. lower leg length 3. seat depth 4. seat width 5. overall width 6. push bar height 7. shoulder height
| EASyS Advantage 1 | EASyS Advantage 2 | |
|---|---|---|
| Seat depth | 19 – 30 cm / 7.5 – 11.8″ | 27 – 38 cm / 10.6 – 15″ |
| Seat width | 19 – 31 cm / 7.5 – 12.2″ | 25 – 37 cm / 9.8 – 14.6″ |
| Seat height | 47 cm / 18.5″ | 46 cm / 18.1″ |
| Back height | 41,5 – 68 cm / 16.3 – 26.7″ | 55 – 74 cm / 21.7 – 29.1″ |
| Lower leg length | 17,5 – 29 cm / 6.9 – 11.4″ | 21 – 37 cm / 8.3 – 14.6″ |
| Hip angle | 90° to 180° | 90° to 180° |
| Knee angle | 90° to 180° | 90° to 180° |
| Foot angle | 78° to 100° | 78° to 100° |
| Turning range of seat | 180° | 180° |
| Size of hip guide (w x h) | 23 x 12 cm / 9 x 4.7″ | 30 x 15 cm / 11.8 x 5.9″ |
| Size of foot rest (w x d) | 28 x 18 cm / 11 x 7.1″ | 32 x 21 cm / 12.6 x 8.3″ |
| Weight | 9 kg / 19.5 lbs | 10.4 kg / 22.9 lbs |
| Carrying capacity (seat) | 35 kg / 77.1 lbs | 40 kg / 88.2 lbs |
| Overall width | 59.5 cm / 23.4″ | 69 cm / 27.2 |
| A-Chassis Advantage, size 1 | A-Chassis Advantage, size 2 | |
|---|---|---|
| Seat tilt-in-space (driving direction) | -10° to +35° | -10° to +35° |
| Seat tilt-in-space (face to face) | -10° to +35° | -10° to +35° |
| Push bar height | 71.5 – 117 cm / 28.2 – 46.1″ | 71.5 – 117 cm / 28.2 – 46.1″ |
| Wheel size swivel wheels (front) | 18 cm / 7.1″ | 18 cm / 7.1″ |
| Wheel size (rear) | 25 cm / 10″ | 25 cm / 10″ |
| Weight (chassis) | 9.8 kg / 21.6 lbs | 10.9 kg / 24 lbs |
| Carrying capacity (basket) | 5 kg / 11 lbs | 5 kg / 11 lbs |
| Carrying capacity (incl. seat) | 50 kg / 110.2 lbs | 55 kg / 121.2 lbs |
